Part # : 19BM99
5 W/ft General Purpose Constant-Wattage Heating Cable, Stainless Braid, 120V
Part # : 19BM99
5 W/ft General Purpose Constant-Wattage Heating Cable, Stainless Braid, 120V
Product Suggestions
Item Subtotal:
19BM99 is a general purpose constant wattage heating cable with a stainless steel overbraid. This cable operates at 120 VAC with a cable type of 5 watts/ft, and can be cut to preferred length at the job site. The maximum exposure temperature is 400° F (204° C). Product is moisture, chemical, flame, and radiation resistant, making it great for temperature applications such as food and chemical processing, water lines, fire protection systems, and more. Other cable types and voltages available upon request. This product requires a temperature controller for safe operation.
*Quantity is by the foot, minimum of 50 ft.
**This product requires a temperature controller for safe operation.
**This product requires a temperature controller for safe operation.
- Quantity Qty Price
- 50 $6.330 ea.
- 100 $5.860 ea.
- 200 $5.630 ea.
- Case Pack: 50' Roll
Related Products
Product | Price | Qty | Request | |
---|---|---|---|---|
![]() Part #: 19BV72 BriskHeat® High Capacity Bulb and Capillary Temperature Controller, 0°-150°F, 120V, 1 Contactor This 0°-150°F high capacity bulb and capillary temperature controller features 1 contactor element. This temperature controller is designed for general purpose use in indoor and outdoor environments for applications that require automatic control. Bulb |
| | ||
![]() Part #: 19BV73 BriskHeat® High Capacity Bulb and Capillary Temperature Controller, 50°-300°F 120V, 1 Contactor This high capacity bulb and capillary temperature controller has 1 contactor and a 50°-350°F temperature range. This temperature controller is designed for general purpose use in indoor and outdoor environments for applications that require automatic c |
| | ||
![]() Part #: 19BV74 Ideal for general purpose applications in indoor and outdoor environments, this high capacity bulb and capillary temperature controller features 1 contactor and a 150°-650°F temperature range. Bulb and capillary temperature controllers are ideal for hi |
| | ||
![]() Part #: 19BV84 BriskHeat® High Capacity Bulb and Capillary Temperature Controller, 0°-150°F, 120V, 2 Contactors This high capacity bulb and capillary temperature controller with 2 contactors is designed for use in indoor and outdoor environments for applications that require automatic control and has a 0°-150°F temperature range. Bulb and capillary thermostats a |
| | ||
![]() Part #: 19BV85 BriskHeat® High Capacity Bulb and Capillary Temperature Controller, 50°-300°F, 120V, 2 Contactors Ideal for general use in indoor and outdoor environments for applications that require automatic control, this high capacity bulb and capillary temperature controller has a 50°-350°F temperature range and 2 contactors. Bulb and capillary thermostats ar |
| | ||
![]() Part #: 19BV86 BriskHeat® High Capacity Bulb and Capillary Temperature Controller, 150°-650°F, 120V, 2 Contactors This high capacity bulb and capillary temperature controller features 2 contactors and a 150°-650°F temperature range. This temperature controller is designed for general use in indoor and outdoor environments for applications that require automatic co |
| | ||
![]() Part #: 19B668 19B668 is a BriskHeat® automatic On/Off thermostat controller with an on temperature of 35° F (2° C) and off temperature of 50° F (10° C). This thermostat control features a conduit fitting suitable for Class I Division 2 hazardous areas. |
| | ||
![]() Part #: 19B670 19B670 is a BriskHeat® automatic On/Off thermostat controller with an on temperature of 60° F (16° C) and off temperature of 75° F (24° C). This thermostat control features a conduit fitting suitable for Class I Division 2 hazardous areas. |
| | ||
![]() Part #: 19B669 19B669 is a BriskHeat® automatic On/Off thermostat controller with an on temperature of 45° F (7° C) and off temperature of 60° F (16° C). This thermostat control features a conduit fitting suitable for Class I Division 2 hazardous areas. |
| | ||
![]() Part #: 19B671 19B671 is a BriskHeat® automatic On/Off thermostat controller with an on temperature of 90° F (32° C) and off temperature of 105° F (41° C). This thermostat control features a conduit fitting suitable for Class I Division 2 hazardous areas |
| | ||
![]() Part #: 19B672 19B672 is a BriskHeat® automatic On/Off thermostat controller with an on temperature of 185° F (85° C) and off temperature of 200° F (93° C). This thermostat control features a conduit fitting suitable for Class I Division 2 hazardous area |
| |
- Specifications
- 19BM99 is a general purpose constant wattage heating cable with a stainless steel overbraid. This cable operates at 120 VAC with a cable type of 5 watts/ft, and can be cut to preferred length at the job site. The maximum exposure temperature is 400° F (204° C). Product is moisture, chemical, flame, and radiation resistant, making it great for temperature applications such as food and chemical processing, water lines, fire protection systems, and more. Other cable types and voltages available upon request. This product requires a temperature controller for safe operation.
Key benefits:- Power remains constant regardless of temperature
- Dimensions: 0.2" x 0.3" (5mm x 8mm)
- 40lb (18kg) per 500-foot (152m) spool
- 5 W/ft (16 W/m)
- 12AWG bus wires
- Ideal for long runs
- Tension wrapping holds resistance wire in place, even under extreme bending
- 1 year warranty
- Proudly Made in the USA
- CID2, Groups B, C, D
- CIID2, Groups F, G
- CIIID2
- Mid range process temperature control for food and chemical processing facilities
- Water lines
- Fire protection systems
- Fuel oil
- Condensate return
- Lines periodically purged with 250 psig steam
Downloads:
Disclaimer:
This information has been provided as a general guide. It is the customer's responsibility to select the proper container for product and application compatibility.Additional Information
More Information Color Stainless Steel Voltage 120v Wattage 5 W/ft Weight 0.068 lbs. Case Pack 50' Roll Case Dimensions 16" L x 16" W x 12" H Country of Manufacture United States Manufacturer BriskHeat® Model FECAB5120SS Note: *Quantity is by the foot, minimum of 50 ft.
**This product requires a temperature controller for safe operation. - Q & A
